Application

The arc design of the flow channel of the plug valve core ensures that the medium is not stranded, the handle rotates 90 degrees to achieve the function of switching pipeline channel, the operation torque is small, the quick and convenient is the first choice product of the food grade switching pipeline. Widely used in beer beverage production, milk processing production line, reagent mixing and other sanitary aseptic production systems.

Specifications

Specification：1"-4", DN25-DN100

Working pressure：0～6bar
Connection：clamp, weld, thread

Connection standard：3A DIN SMS ISO
Valve structure：straight, three way

Materials：304, 316L

Internal surface：Ra0.4～0.8μm

External surface：Ra0.8～1.6μm
